LT860 Pigment CIJ Printer
LT800 Series
Newly upgrade information editor, more suitable for user’s operation habits; Intelligent real-time communication function, best fit for automated production enterprises, effectively improve production accuracy, generate more benefits.
Continuous and stable performance, fully adaptable for high-speed production line.
Model | LEAD TECH LT860 Pigment Inkjet Printer |
Material | Stainless steel |
Printing Performance | 1-4 Lines(7X5matrix) 1-5 Lines(5×5 matrix) Max speed=287m/min@5X5 |
Font Matrix | Single-Line:5X5,7X5,9x6,12X8,16X11,19X14,24X17,32X22 Twin-Line:5X5,7X5,9x6,12X8,16X11 3 Lines:5X5,7X5,9x6 4 Lines:5X5,7X5 5 Lines:5X5 |
Printing Distance | Font Height:1-15mm Printing distance:2mm to 30 mm Best: 10mm |
Operating System | LT-Touch unique System, Multiple Languages |
Print Content | English,Chinese,Arabic Numbers, serial number, Barcode, Shift, DM/QR Code, Gs1, Logo,UPC A&E, EAN 8 & 13, UCC/EAN 128,Code 128 A, B & C, Code 39, Code 125,automatic date/time/expiry date, special characters, etc. |
Extra Memory | USB.RS485.Ethernet |
System Language | Chinese,English,Korean,Russian,Polish, Persian,Arabic,Spanish,German, Indonesian, Thai, Vietnamese, Croatian, Slovenian, Slovak, Bosnian, Portuguese, Italian,etc. |
Memory Storage | 1000+Messages |
Industrial Protection | IP55 |
Printhead | Super soft, length 3m constant temperature,60μm |
Printing Direction | 360° All-round printing |
Cartridge Volume | Ink(500ml) Make-up (750ml) |
Temperature/Humidity range | 0-45℃ 0-95% Relative Humidity, Non-condensing |
Power | 100-120/200-240V~ , 50-60Hz , 0.72 - 0.36A , 80W |
Easy Operation
Linux system, 7 inch touch screen
User friendly interface, easy operation, fast learning
Support text or modules to be dragged manually
Support Data Matrix, QR Code
Stable & Reliable
Stainless steel cabinet with Teflon coating, easy for cleaning
Stronger Anti-interference capability, suitable for harsh environment
All-in-One InkCore, stable running
Lifetime up to 6000 hours
Superior Quality
Water-proof keyboard, IP55
Fulled sealed electronic cabinet, dust-proof
Innovative Printhead
Injection molding Technology, prevent ink leakage
Auto-cleaning function, reduce nozzle blockage
Stable long-time performance, reliable quality
Smart Ink System
Plug-n-play, less contamination
Efficient utilization, saving production cost
IoT Industry 4.0
Support RS485 & USB port
Support Ethernet port (Network Version)
Connect with external device, such as PC, PLC, scanner, checkweigher...etc.
Realize information exchange and interconnection
Plastic
Paper Board
Flexible Film
Metal Cans and Caps
Glass
Plastic Rigid Containers
Model |  LT860 Pigment Inkjet Printer |
Material | Stainless steel |
Printing Performance | 1-4 Lines(7X5matrix) 1-5 Lines(5×5 matrix) Max speed=287m/min@5X5 |
Font Matrix | Single Line:5X5,7X5,9x6,12X8,16X11,19X14,24X17,32X22 Twin-Line:5X5,7X5,9x6,12X8,16X11 3 Lines: 5X5,7X5,9x6 4 Lines:5X5,7X5 5 Lines: 5X5 |
Printing | Font Height:1-15mm Printing distance:2mm to 30 mm Best: 10mm |
Operating System | LT-Touch unique System, Multiple Languages |
Print Content | English,Chinese,Arabic Numbers, serial number, Barcode, Shift, DM/QR Code, Gs1, Logo,UPC A&E, EAN 8 & 13, UCC/EAN 128,Code 128 A, B & C, Code 39, Code 125, automatic date/time/expiry date, special characters, etc. |
Extra Memory | USB, RS485, Ethernet |
System Language | Chinese,English,Korean,Russian,Polish, Persian,Arabic,Spanish,German, Indonesian, Thai, Vietnamese, Croatian, Slovenian, Slovak, Bosnian, Portuguese, Italian,etc. |
Memory Storage | 1000+Messages |
Industrial Protection | IP55 |
Printhead | Super soft, length 3m constant temperature,60μm |
Printing Direction | 360° All-round printing |
Cartridge Volume | Ink(500ml) Make-up (750ml) |
Temperature/ Humidity range | 0-45℃ 0-95% Relative Humidity, Non-condensing |
Power | 100-120/200-240V~ , 50-60Hz , 0.72 - 0.36A , 80W |
